Boiler ready for Hydraulic Testing

Tyseley have completed the fitting of the large tubes and so the boiler is now ready for its hydraulic test. This is expected to take place within the next 7-14 days paving the way for the steam test.

Meanwhile the ash pan nears completion ready for the day it can be fitted into the frames followed by the boiler itself. Our teams continue to work on the locomotive whilst planning to make the cladding for the blackhead once the boiler goes on

Lates news from Tyseley

Our team again spent a working day at Tyseley after the summer break finding much progress on the pipe work being undertaken during the previous month.

The boiler is more advanced too with the large tubes now complete with their bottle ends. Currently the tubes are away for testing and expected back at Tyseley within days ready for fitting. It should not be much longer before the anticipated hydraulic test.

Meanwhile assembly of the Ashpan has progress so that it’s ready for when the boiler finally sits in the frames.

First Tubes in Boiler

This week engineers at Tyseley fitted most of the small tubes to the boiler, cutting them to length and sliding them in. The large tubes will follow.

Brake Rigging & Cylinder Cocks

Our team checked over the fully fitted brake rigging which is now nearing completion and also fitted the cylinder drain cocks and mechanism.

With the locomotive over the pit we were able to view the completed valve gear, the first picture shows the weigh shaft and expansion link looking forward and the second photo the reverse view showing the sheaves mounted on the middle axle.

More work at Tyseley

Last weekend at Tyseley work continued fitting the cylinder lagging and completing the brake rodding. Meanwhile the boiler has been passed by the inspector to have the tubes fitted.

Latest Progress

The following pictures illustrate the latest progress from both Tyseley and Llangollen.

At Tyseley the coupling rods have been fitted to the wheels, whilst preparation of the connecting rods has taken place adding paint to the rear of the rods. The boiler is edging ever nearer to completion with the fire hole inner and outer sheets riveted. At Llangollen the further painting of the tender is ongoing.

More progress as locomotive goes together

as the following photographs illustrate, both the pistons and valves are now in the cylinders and the end caps fitted. Also the brake rigging is on.

‘The boiler is making progress too with the large tubes now on site and the ‘bottle ends’ are being fitted. Finally the superheater elements are being manufactured.

Latest Progress 2nd February 2019

The first weekend in February also saw the first Volunteer working day of the year on Betton at Tyseley Locomotive Works. TLW staff have carried out work on the frames and re-wheeling, then it was our turn to put the springs back on. Also delighted to see that the Boiler has now been fully riveted, and just awaiting some final stays before it is to be tubed, very shortly, TLW staff have also been placed the pistons into the cylinders. Thankyou, as ever, to all our volunteers for their hardwork to Chris, Quentin, Barry, Paul 1, Paul2, Mick, Colin, Bill, RichS and Lynn for the well needed refreshments!

2018 Raffle Ticket Results

Winning raffle ticket numbers

1st prize 2000

2nd prize3170

3rd prize 1482

4th prize 4603

We will be contacting you over the next day or two



The Betton Grange Team

Boiler Trial Fitted

The boiler has been trial fitted into the locomotive to determine clearances and any other work needed before the tubes are fitted and an hydraulic test carried out. The work on the firebox is complete and the front taper section has been bolted on. The smoke box will be connected too before further work takes place.
